Airborne Particle Counter A110(100L/min)

loading

Share to:
Airborne Particle Counter (APC) is fully compliant with ISO14644-2015 and ISO21501-4 standard.



Capacitive touch screen

Zone



8.0″

20,000









Data

Portable



5 million sets

6.1Kg




Availability:

Product Feature

8 inch capacitive touchscreen, quick response

Even with two pairs of latex gloves

Sealed 316L stainless steel enclosure and dust plug to prohibit dust and water



Compliance with FDA21 CFR Part 11

Automatically Collect Air Samples

APC data exceed the limit,triggers the BAS to start sampling

Operation Interface



 Data

  • Standard report: one key to generate ISO/EUGMPI CHINESEGMP reports.

  • Data review and data export.

 1. Sum up data by zone.

 2. Freely switch counting unit between △/Σ/#, m /ft.

 3. Automatically generate UCL values and  average values

 4. Search for sample records precisely by time, zone and operator.

  • Data integrity: featured with audit trail.


 Sampling


  • Real-time concentration curves, to get a better understanding of environmental particle condition.

  • Quick editing function, to make sampling more flexible.



 Setup

  • Clear layout for orders. Simple and easy to use.

  • One-click for system software upgrade.

  • Multiple sets of personalized sampling schemes can be customized for any zone.

SPECIFICATIONS



  • FLOW RATE： A110: 100LPM±3%

  • SIZE RANGE： A110: 0.5µm-25µm

  • SIZE CHANNELS： A110: 0.5µm, 1.0µm, 2.0µm, 3.0µm, 5.0µm, 10.0µm

  • SIZE RESOLUTION： <15% @ 0.5µm (meets ISO 21501-4)

  • COUNT EFFICIENCY：  A110: 50% ±20% for 0.5µm, 100% ±10% for >0.75µm (meets ISO 21501-4 and JIS B9921)

  • CONCENTRATION LIMIT：  A110: 560,000 particles/ft³at 10% coincidence loss

  • ZERO COUNT：  <1count/5min

  • EXHAUST：  Internal HEPA filter (>99.997%@0.3µm)

  • ZONE/ LOCATION：  20,000 rooms and 200,000 locations

  • SAMPLING TIME：  1 second to 168 hours

  • CYCLES：  1000 samples on one location

  • LASER SOURCE：  Long life laser

  • DATA STORAGE：  3.5G, ≥5,000,000 sets of sample records

  • DISPLAY：  8” LCD capacitive touch screen

  • LANGUAGE：  Chinese, English

  • DATA RELIABILITY：  Compliant with 21 CFR Part 11

  • REPORTS：  Compliant with ISO/EUGMP/CHINESEGMP/Fed Std

  • CALIBRATION FREQUENCY：  Recommend at least once a year

  • DIMENSIONS (HXWXD)：  254x204x263mm

  • WEIGHT：  6.1Kg (13.45lbs) (without battery)

  • ENCLOSURE：  316L Stainless Steel

  • POWER：  AC 100-240V, 50 Hz/60 Hz

  • BATTERY：  10.8V, 9000mAh, rechargeable lithium battery

  • BATTERY ENDURANCE：  A110: running for 4 hours

  • MAX POWER：  consumption AC 90W

  • OPERATING CONDITIONS TEMPERATURE: 5℃-35℃, relative humidity up to 95%

  • STORAGE CONDITIONS TEMPERATURE： -10℃-40℃, relative humidity up to 98%

  • SAFETY：  EN 61010-1:2010, EN 61326-1:2013, EN 61326-2-2:2013,EN 60825-1:2014, EN 61000-6-1:2007, EN 61000-6-3:2007+A1,FCC Part 15, Subpart B

  • WARRANTY：  2 years after activation


Airborne Particle Counter



Airborne Particle Counter Brochure.pdf
