Airborne Particle Counter A120(50L/min)

Airborne Particle Counter (APC) is fully compliant with ISO14644-2015 and ISO21501-4 standard.



Capacitive touch screen	Zone
8.0″	20,000

Data	Portable
5 million sets	6.1Kg

Availability:

PRODUCT DETAILS

SPECIFICATIONS

RESOURCES

VIDEO

PRODUCT FEATURE

8 inch capacitive touchscreen, quick response

Even with two pairs of latex gloves

Sealed 316L stainless steel enclosure and dust plug to prohibit dust and water

Compliance with FDA21 CFR Part 11

AUTOMATICALLY COLLECT AIR SAMPLES

APC data exceed the limit,triggers the BAS to start sampling

OPERATION INTERFACE

Data

Standard report: one key to generate ISO/EUGMPI CHINESEGMP reports.
Data review and data export.

1. Sum up data by zone.

2. Freely switch counting unit between △/Σ/#, m /ft.

3. Automatically generate UCL values and average values

4. Search for sample records precisely by time, zone and operator.

Data integrity: featured with audit trail.

Sampling

Real-time concentration curves, to get a better understanding of environmental particle condition.
Quick editing function, to make sampling more flexible.

Setup

Clear layout for orders. Simple and easy to use.
One-click for system software upgrade.
Multiple sets of personalized sampling schemes can be customized for any zone.

SPECIFICATIONS

FLOW RATE： A120: 50LPM±3%
SIZE RANGE: A120: 0.3µm-25µm
SIZE CHANNELS： A120: 0.3µm, 0.5µm, 1.0µm, 3.0µm, 5.0µm, 10.0µm
SIZE RESOLUTION： <15% @ 0.5µm (meets ISO 21501-4)
COUNT EFFICIENCY： A120: 50% ±20% for 0.3µm, 100% ±10%for >0.45µm (meets ISO 21501-4 and JIS B9921)
CONCENTRATION LIMIT：A120: 840,000 particles/ft³at 10% coincidence loss
ZERO COUNT： <1count/5min
EXHAUST： Internal HEPA filter (>99.997%@0.3µm)
ZONE/ LOCATION： 20,000 rooms and 200,000 locations
SAMPLING TIME： 1 second to 168 hours
CYCLES： 1000 samples on one location
LASER SOURCE： Long life laser
DATA STORAGE： 3.5G, ≥5,000,000 sets of sample records
DISPLAY： 8” LCD capacitive touch screen
LANGUAGE： Chinese, English
DATA RELIABILITY： Compliant with 21 CFR Part 11
REPORTS： Compliant with ISO/EUGMP/CHINESEGMP/Fed Std
CALIBRATION FREQUENCY： Recommend at least once a year
DIMENSIONS (HXWXD)： 254x204x263mm
WEIGHT： 6.1Kg (13.45lbs) (without battery)
ENCLOSURE： 316L Stainless Steel
POWER： AC 100-240V, 50 Hz/60 Hz
BATTERY： 10.8V, 9000mAh, rechargeable lithium battery
BATTERY ENDURANCE： A120: running for 7 hours
MAX POWER： consumption AC 90W
OPERATING CONDITIONS TEMPERATURE: 5℃-35℃, relative humidity up to 95%
STORAGE CONDITIONS TEMPERATURE： -10℃-40℃, relative humidity up to 98%
SAFETY： EN 61010-1:2010, EN 61326-1:2013, EN 61326-2-2:2013,EN 60825-1:2014, EN 61000-6-1:2007, EN 61000-6-3:2007+A1,FCC Part 15, Subpart B
WARRANTY： 2 years after activation
