Flow Rate | 28.3LPM ± 5% |
Size Range | From 0.3µm to 25µm |
Size Channel | 0.3µm, 0.5µm, 5.0µm |
Size Resolution | <15% @ 0.5µm (ISO 21501-4) |
Count Efficiency | 50% ±20% at 0.3µm, 100% ±10% for particles >0.45µm (ISO 21501-4 and JIS B9921) |
Concentration Limit | 450,000 particles/ft³ at 10% coincidence loss |
Zero Count | <1count/5min |
Exhaust | Internal HEPA filter (>99.999%@0.3µm) |
Flow Rate Control | Built-in mass flow sensor, closed-loop auto control |
Laser Source | Long-life laser |
Communication | RJ45, USB, SENSER-HUB, WIFI |
Data Storage | 4GB, default cache for 15,000 records, expandable up to 5 million records |
Alarm | Audible built-in alarm, external sound and light alarm |
Display | 4"LCD capacitive touch screen | status indicators |
Language | Chinese, English | N/A |
Blower | Built-in blower |
Calibration Frequency | Recommended once a year |
Calibration Standard | Meets ISO 21501-4 |
Dimensions (H×W×D) | 163×153×125 mm / 6.42×6.02×4.92 in | 162×148×110 mm / 6.37×5.81×4.33 in |
Weight | 1.95 kg / 4.30 lbs | 1.85 kg / 4.08 lbs |
Enclosure | Aluminum or 316L stainless steel |
Power | 100-240V, 50Hz/60Hz AC to 24V DC input, plug compatible with standard interface types |
Max Power Consumption | AC 90W |
Operating Conditions | Operating temperature: 5℃-35℃ (41℉-95℉), Relative humidity: 5%-90%, non-condensing |
Storage Conditions | Storage temperature: 0℃-40℃ (32℉-104℉), Relative humidity: 5%-95%, non-condensing |
Safety | EN 61010-1:2010, EN 61326-1:2013, EN IEC 61326-1:2021 |
Warranty | 24 months (starting from the date of activation of the product or 6 months after delivery, whichever comes frst) |
