Product Details

BioAerosol Monitoring System (2.83LPM) M120

BioAerosol Monitoring System (2.83LPM) M120

Real-time microbial detection built for pharmaceutical cleanrooms.

The M120 BioAerosol Monitoring System (BAMS) continuously tracks airborne microbial activity in your production environment, giving your team the data to act immediately and avoid the costly losses that come with delayed contamination detection. Where traditional methods leave you waiting on incubation results, the M120 delivers answers in real time.

Feature Detail

Display 8.0″ Capacitive touch screen

Weight 6.8Kg

Monitoring 24/7 hr

Storage 119 GB

Model:
M120

Availability:

PRODUCT DETAILS

SPECIFICATIONS

RESOURCES

PRODUCT FEATURES

Continuous, not just periodic

Real-time airborne microbial monitoring,

running around the clock

Compliant by design

ISO 21501-1 compliant particle counter, conforms

to FDA 21 CFR Part 11

Built for people

A streamlined, intuitive interface for efficient

use by technicians

Truly portable

Easy transportable for daily monitoring or

investigation, first truly portable microbial

monitoring device

4cba9

Compliant with FDA 21 CFR Part 11

PRINCIPLE

Particle detecting: Mie scattering

5f221

Biological particle detecting: Laser induced flouresence

How It Works

The M120 combines two detection principles to identify biological particles as they occur:

Particle detection — Mie scattering
Biological particle detection — Laser-induced fluorescence

Real-Time Results with BAMS

Conventional airborne microbial monitoring relies on interval-based, ad-hoc, or event-triggered sampling, and then requires incubation for results. The BAMS counts microbes as autofluorescence units (AFU), and results are available immediately, with no culturing or manual counting required.

Compendial Methods vs. the BAMS
	COMPENDIAL METHOD	M120 (BAMS)
Speed	Results in 1–7 days, with frequent scheduled and unscheduled interruptions	Immediate results
Contamination Tracing	Root cause is difficult to pinpoint after the fact	Root cause is identifiable in real time
Monitoring approach	Sampled, with reduced accuracy and limited trend visibility	Continuous, with rich trend data for deeper analysis
Risk Profile	Higher exposure to contamination and production	Lower contamination and production-loss risk
Resources	Labor-intensive, with built-in time delays	Minimal resource draw, online and immediate

SPECIFICATIONS

SIZE RANGE: 0.5µm - 25µm
LASER SOURCE: Long life laser
COUNT EFFICIENCY: 50% ±20% for 0.5µm, 100% ±10% for >0.75µm (meets ISO 21501-4 and JIS B9921)
FLOW RATE: 2.83LPM±3%
ZONE / LOCATION: 20,000 rooms and 200,000 locations
SAMPLING MODE: Manual, auto, beep, cumulative count Σ/ differential count Δ or concentration
CONCENTRATION LIMIT: 4,000,000 particles/ft³at 10% coincidence loss
EXHAUST: Internal HEPA filter (>99.999%@0.3µm)
COMMUNICATION: RJ45, USB, SENSER-HUB, WIFI (optional)
EXPORT FILE: PDF file or EXCEL file
DATA STORAGE: 119GB
DATA SECURITY: Authority management, authority level divide into admin, operator and supervisor
ALARM: Audible built-in alarm
DIMENSIONS (HxWxD): 10x7.87x10.39 in/255x200x264mm (with handle and foot mat)
WEIGHT: 14.9lbs/6.8Kg (with battery), 12.8Ibs/5.8kg(witout battery)
ENCLOSURE: 316L Stainless Steel and anodized aluminum
OPERATING CONDITIONS: 5°C -35° C / 41°F - 95°F, Relative humidity: 5-90% non-condensing
STORAGE CONDITIONS: 0°C -40° C / 32°F - 104°F, Relative humidity: 5-95% non-condensing
SAFETY: EN 61010-1:2010+A1:2019, EN 61326-1:2013, EN 61326-2:2:2013, EN 60825-1:2014, EN 61000-6-1:2007, EN 61000-6-3:2007+A1, EN 62311:2008, EN 62479: 2010
Warranty: 12 months (calculated from the date of product activation or six months after the date of manufacture, whichever comes first)
