Touch Screen BioAerosol Monitoring System for Sterility Test
BioAerosol Monitoring System (BAMS) is used for real-time environmental monitoring of microorganisms in the air.
Capacitive touch screen 8.0″
Portable 5.8Kg
Continuous monitoring 7*24hr
Mass storage 119G
Principle
Particle detecting: Mie scattering
Biological particle detecting: Laser induced flouresence
Waiting Time vs Realtime
Current airborne microbial monitoring uses interval, ad-hoc and event-driven sample collections, which require incubation.BAMS uses AFU to count microbes,and the monitoring results can be viewed in real time without the need for culture or courting.
SPECIFICATIONS
SIZE RANGE: 0.5µm - 25µm
LASER SOURCE: Long life laser
COUNT EFFICIENCY: 50% ±20% for 0.5µm, 100% ±10% for >0.75µm (meets ISO 21501-4 and JIS B9921)
FLOW RATE: 5LPM±3%
ZONE / LOCATION: 20,000 rooms and 200,000 locations
SAMPLING MODE: Manual, auto, beep, cumulative count Σ/ differential count Δ or concentration
CONCENTRATION LIMIT: 4,000,000 particles/ft³at 10% coincidence loss
EXHAUST: Internal HEPA filter (>99.997%@0.3µm)
COMMUNICATION: RJ45, USB, SENSER-HUB, WIFI
EXPORT FILE: PDF file or EXCEL file
DATA STORAGE: 119G
DATA SECURITY: Authority management, authority level divide into admin, operator and supervisor
ALARM: Audible built-in alarm
DIMENSIONS (HxWxD): 10x7.87x10.39 in/255x200x264mm (with handle and foot mat)
WEIGHT: 12.8lbs/5.8Kg (without battery)
ENCLOSURE: 316L Stainless Steel and anodized aluminum
OPERATING CONDITIONS: Temperature: 5°C -35° C / 41°F - 95°F, Relative humidity: 5-90% non-condensing
SAFETY: EN 61010-1:2010, EN 61326-1:2013, EN 61326-2:2:2013, EN 60825-1:2014, EN 61000-6-1:2007, EN 61000-6-3:2007+A1, FCC Part 15, Subpart B, EN 300 328 V2.1.1: 2016, ETSI EN 301 489-1 V2.2.0: 2017, ETSI EN 301 489-17 V3.2.0: 2017, EN 62311:2008, EN 62479: 2010
